Ischgl Gampenbahn Lift Will Be Replaced By A Record Breaking 6-Seat Chairlift

In 1988, the detachable 4-seat chairlift Gampen was the biggest construction project by Silvrettaseilbahn AG. At the time, the lift was the longest chairlift in Austria and was completed in a record construction time of just 5 months. Now, after 20 winters and some 13 million trips, the Gampenbahn lift will be replaced by a modern 6-seat chairlift of the latest generation in summer 2018.
The lower terminus (1,924 m) is located in the so-called Fimba and leads along 21pillar locations or 25 round-pipe pillars to one of the most beautiful and highest located spots in the ski area, Palinkopf mountain.
Design
From the entry barrier all the way to the upholstery of the highly comfortable seats, everything was given a completely new design for the new Gampenbahn lift. The backs of the seats of the new facility were printed with images of the stars of the surrounding alpine world this time. Now various animals can be seen on the seatbacks. Every seat is unique.
World record
With 924 m difference in altitude, the Gampenbahn lift covers the greatest elevation difference of any 6-seat chairlift in the world. In order to manage this, a haulage cable with a diameter of 58 mm and a weight of 65 tonnes is required.
Comfort
Highest passenger comfort and low-noise operation make the new Gampenbahn lift first class. The new high-tech chairlift features a series of tangible improvements for guests:
  • ergonomically shaped individual seats
  • 520 mm wide seats with heating
  • safety-optimised design
  • optimised safety restraining bar
  • for very quiet operation and thus special comfort for our guests, this facility is particularly low-noise and low-vibration.
Environment
When building the new lift, environmental concerns were also taken into account. Thus with the new cable run, no less than 4 pillar locations could be left out. The 4-seat chairlift is disassembled into its individual components and planned to be reassembled in another winter sports resort.
The new lift is scheduled to go into operation in time for the new winter season 2018/19. You can read about the current state of the construction works in the construction blogger on www.ischgl.com.
Keydata for the new Gampenbahn lift
  • Type: 6 CLD/B-H
  • Transport capacity: 2,800 passengers per hour
  • Inclined length: 2,416 m
  • Height above sea level lower terminus: 1,924 m
  • Height above sea level upper terminus: 2,848 m
  • Elevation difference: 924 m
  • Number of pillars: 21
  • Travel time: approx. 7.87 min.
  • Number of chairs: 122
  • Chair features: weather-protection hoods, heated seats, D-Line
  • Persons per seat: 6
  • Location of drive engine: Upper terminus
  • Maximum cable incline:74 %
  • Manufacturer cable car technology: Doppelmayr Seilbahn GmbH
  • Haulage cable: Teufelberger Seil GesmbH
  • Drive/control technology: Frey Austria GmbH
  • Investment volume:approx. € 16.5 M (incl. restaurant)
Right by the lower terminus of the new Gampenbahn lift, a new innovative self-service restaurant is being built.
This new gastronomic highlight will bring the ski area right into the restaurant. For example, you will be served your food from a gondola and can put down your plates on a snow gun. The restaurant was designed from top to bottom by a renowned star designer down to the smallest detail.
From the upper terminus of the Mullerbahn M2 to Alp Trida, the new ski slope 68 b will be constructed in the summer of 2018. This will give birth to a new additional ski-run (difficulty level: medium) with a length of round 1 km and an elevation difference of some 250 m. The new downhill run will also get an artificial snowmaking system.
The new full-service restaurant Gampenalpe is located directly by the red ski slope No. 40 at 1990 m above sea level, some 400 m from the lower terminus of the new chairlift Gampen E4.
The new rustic ski lodge in the Ischgl/Samnaun ski area will feature some 100 seats with full service. Preliminary work on the new restaurant was already started in autumn 2018 .
Treat yourself to some traditional regional Tirolean cooking at the new Gampenalpe starting in December 2018.
The Silvrettaseilbahn AG employs some 550 staff during winter and is one of the most important employers in Tirol. The Bergbahnen Samnaun AG and the Silvrettaseilbahn AG together operate 45 cable cars and lifts, 239 kilometres of slopes and 12 mountain restaurants in the Silvretta-Arena ski area. Since the company was established, the shareholders have foregone any dividend payout in order to allow investment into the ski area.
